The SX40C is a compact SWR-power meter. Featuring cross needle design for measuring SWR and output power simultaneously. Compact size makes it very useful for testing mobiles as well as base station installation.


  • Frequency range: 140 to 525MHz.
  • Power display range: 15W 150W.
  • Accuracy at full scale: 10%AT.FS.
  • Minimum power at SWR measurement: 3W.
  • Connector: M-J.
  • Dimensions: 85Wx87Hx95Dmm.
  • Weight: 270g.
  • Impedance: 50ohms.
